H9 H.265 4G SDI h 264 encoder hd encoders

Product Description

1-channel HD SDI input, 1channel LINE-IN audio.

Dual streams output. H.265/ H.264 format, Audio: MP3, AAC, G.711 format.

Configuration could be freely adjusted according to the need.

Support HTTP / RTSP / RTP/ TCP / RTMP / RTMPS / UDP / ONVIF / HLS protocols.

Red indicator: power. Yellow: Network. Green:Streaming status

Key features

1. SDI to 3g/ 4g/ wifi/ LAN.
2. Standard hot shoe
3. Resolution: up to 1920x1080p 60 (customized)
4. Supports WINDOWS ,LINUX,MAC OS
5. Support RTSP/ RTP/ RTMP/ HTTP/ ONVIF/ HLS/ UDP unicast and multicast protocol
6. Support Main TS stream and the sub TS stream  use in different network protocols for transmission
7. Encoding level: 1, 2, 3, 4 and 5 (the higher the level, the larger of the code flow fluctuation ratio )
8. Coding Standard: Base line profile/ main profile/high profile, H.265 main profile:
9. Audio: MP3, AAC, G.711, sampling rate: 32000,44100, etc, encoded audio bit rate: 48K, 64K, 96K, 128K, 160K, 192K, 256K
10. Video bitrate Control: CBR / VBR 16KBIT / S ~ 12MBIT / S
11. Video packaging: A mode: FFMPEG, B mode: VLC
12. Transmission: TCP, UDP, 100M/ 1000M (RJ45 Duplex network port)
13. Support WEB access in Chinese/ English, passwords change, WAN remote management (WEB)
14. Support Text/ image OSD, images superimposing.
15. Adjustable coordinates: 1920×1080; the font size: 8 to 72.
16. Supports automatically obtain IP (DHCP), support One-key recovery, upgrade and remote maintenance.
17. Image settings: contrast ratio, brightness, tones, saturation, noise detection, sharpness, filtering
18. Support build-in or external audio input, support left and right sound channel, Support audio gain, turn volume individually.
19. Support encoding without video signal;
20. Take effect immediately when applied the settings, don’t need to restart.
21. Support one-key recovery to default setting.
22. Battery capacity：10000MHA, Low power consumption design, the battery can be working 5-6hours.

Specification
