H8 HDMI WiFi Battery 4G h 264 encoder hd encoders
H8 HDMI WiFi Battery 4G h 264 encoder hd encoders
H8 HDMI WiFi Battery 4G h 264 encoder hd encoders
H8 HDMI WiFi Battery 4G h 264 encoder hd encoders
H8 HDMI WiFi Battery 4G h 264 encoder hd encoders

H8 HDMI WiFi Battery 4G h 264 encoder hd encoders

Want create site? Find Free WordPress Themes and plugins.                Product Description 1-channel HD HDMI input, 1channel LINE-IN audio. Dual streams output. H.265/ H.264 format, Audio:

Protocol : HTTP, RTSP, RTP, TCP, RTMP, RTMPS, HLS, UDP multicast, unicast

Coding standard : H.265 / H.264

Encoded size : Up to 1920*1080 60FPS

Video bit rate : 5-60 fps

Phone:+86 18926159746 020-36164006
DESCRIPTION FEATURES







Product Description

1-channel HD HDMI input, 1channel LINE-IN audio.

Dual streams output. H.265/ H.264 format, Audio: MP3, AAC, G.711 format.

Configuration could be freely adjusted according to the need.

Support HTTP / RTSP / RTP/ TCP / RTMP / RTMPS / UDP / ONVIF / HLS protocols.

Red indicator: power. Yellow: Streaming status. Green: Network



Key features

  1. HDMI to 3g/ 4g/ wifi/ LAN.
  2. Standard hot shoe
  3. Resolution: up to 1920x1080p 60 (customized)
  4. Supports WINDOWS ,LINUX,MAC OS
  5. Support RTSP/ RTP/ RTMP/ HTTP/ ONVIF/ HLS/ UDP unicast and multicast protocol
  6. Support Main TS stream and the sub TS stream  use in different network protocols for transmission
  7. Encoding level: 1, 2, 3, 4 and 5 (the higher the level, the larger of the code flow fluctuation ratio )
  8. Coding Standard: Base line profile/ main profile/high profile, H.265 main profile:
  9. Audio: MP3, AAC, G.711, sampling rate: 32000,44100, etc, encoded audio bit rate: 48K, 64K, 96K, 128K, 160K, 192K, 256K
  10. Video bitrate Control: CBR / VBR 16KBIT / S ~ 12MBIT / S
  11. Video packaging: A mode: FFMPEG, B mode: VLC
  12. Transmission: TCP, UDP, 100M/ 1000M (RJ45 Duplex network port)
  13. Support WEB access in Chinese/ English, passwords change, WAN remote management (WEB)
  14. Support Text/ image OSD, images superimposing.
  15. Adjustable coordinates: 1920×1080; the font size: 8 to 72.
  16. Supports automatically obtain IP (DHCP), support One-key recovery, upgrade and remote maintenance.
  17. Image settings: contrast ratio, brightness, tones, saturation, noise detection, sharpness, filtering
  18. Support build-in or external audio input, support left and right sound channel, Support audio gain, turn volume individually.
  19. Support encoding without video signal;
  20. Take effect immediately when applied the settings, don’t need to restart.
  21. Support one-key recovery to default setting.
  22. Low power consumption design,  Battery capacity:10000MHA



Specification

Product model H8 3G/4G+ LAN+ WiFi+ battery HDMI Encoder
Input 1Channel HDMI input, 1 Channel line in audio
Output 1 channel IP signal output
Video Input resolution Up to 1920x1080p 60FPS, standard HDMI resolution
Coding standard H.265/ H.264
Coding level H.265 MAIN PROFILE
H.264 BASELINE PROFILE
H.264 MAIN PROFILE
H.264 HIGH PROFILE
Encoded size 640*360~1920*1080(Can customize)
Video bit rate Rate control: CBR/VBR 16KBIT/S~12MBIT/S
Video frame rate 5- 60 fps
OSD Text, Image
Audio Input selection 1 channel embedded audio hdmi, 1 channel 3.5MM independent audio, support audio gain
Audio coding AAC/ MP3/ G.711
Audio bit rate 64Kb/s~384Kb/s
Sampling rate 32000、44100,48000 etc
IP output 1 RJ 100M / 1000M adaptive Ethernet port, dual-stream( H.265/264 TS stream)
System Network protocol HTTP, RTSP, RTMP, ONVIF, HLS, UDP multicast, unicast
Configuration management User interface, remote upgrade, Andriod APP, multi-one management platform
  Power supply 12V~2A
power consumption 5W
Size 103mm * 70mm * 25mm(L*W*H)
Operating temperature -20℃+ 60℃
Working humidity <90%,Non-condensing
Weight 0.4KG

Haiwei reserves the right to adjust the product parameters, if you have any questions please contact us to check
