U10 HDMI SDI VGA YPBPR SDI codec
U10 HDMI SDI VGA YPBPR SDI codec
U10 HDMI SDI VGA YPBPR SDI codec
U10 HDMI SDI VGA YPBPR SDI codec
U10 HDMI SDI VGA YPBPR SDI codec

U10 HDMI SDI VGA YPBPR SDI codec

Want create site? Find Free WordPress Themes and plugins.   Product Description The U10 codec are the embedded hardware for point to point interactive transmission solution, emergency communication, transcoding, broadcasting, live strea

Protocol : RTSP/ RTMP/ UDP/ HTTP/ HLS/ P-P/ SDK

Coding standard : H.265

Encoded resolution : 320*180 to 1080P 60

Power : 12V - 2A

Phone:+86 18926159746 020-36164006
DESCRIPTION FEATURES



Product Description

The U10 codec are the embedded hardware for point to point interactive transmission solution, emergency communication, transcoding, broadcasting, live streaming, Recording and streaming The U10 allowed to receive the stream from other side, then output via HDMI/ 3.5mm composite Jack, meanwhile, able to send the streams via a series of IP protocol like RTSP over UDP & TCP/ RTMP/ HTTP/ UDP /Unicast/ Multicast/ ONVIF/ P-P (Haiwei proprietary protocol).


With Hiawei Powerd proprietary protocol, the U10 supports directly receive the stream from another Haiwei P-P devices in another network, even another country on the Planet.
New technology-SDK decoding, one click to call the SDK for local network transmission, don’t need to transmit over server like P-P solution, ultra low latency will available then.



Full interface, the U10 support optionally input 1* HDMI (v 1.4)/ CVBS/ VGA/ YPBPR/ DVI-D, and 1* SDI (3G/ HD/ SD) simultaneously. Abundant accessibilities serial port supported now, including SATA port for storage, I/O, RS232, GND, RS485A/ B, TX232, RX232

Specification

Input HDMI/VGA/ CVBS/YPBPR/SDI/DVI
HTTP/RTSP/UDP/RTP/RTMP
Video  Resolution Up to 1920x1080P
Trans-coding HTTP, RTSP, RTMP, ONVIF, HLS, UDP multicast, unicast→HTTP, RTSP, RTMP, ONVIF, HLS, UDP multicast, unicast
HTTP, RTSP, RTMP, ONVIF, HLS, UDP multicast, unicast→HDMI/VGA/ CVBS/YPBPR/SDI/DVI
HDMI/VGA/ CVBS/YPBPR/SDI/DVI→HTTP, RTSP, RTMP, ONVIF, HLS, UDP multicast, unicast
Rate Control CBR/ VBR
Audio  Trans-coding AAC/ G.711/ MP3/ MP2
Sampling rate 32000/44100/48000 etc
Bit Rate 64Kb/s~384Kb/s
output IP output 1 RJ45 100M / 1000M adaptive Ethernet port, dual-stream( H.265/264 TS stream)
Interfaces HDMI/VGA/ CVBS/YPBPR/SDI/DVI
System function  Network protocol HTTP, RTSP, RTMP, ONVIF, HLS, UDP multicast, unicast
Configuration management User interface, remote upgrade, multi-one management platform
General  Power supply 220V
power consumption 12W
Weight 3.5KG
Size  430mm x 250mm x 45mm(WxDxH)
Operating temperature -20℃+ 60℃
