HD Live PTZ Camera Z1300

1.12X optical zoom lens, 72.5° wide angle with little distortion.
2.1/2.8 inch high quality CMOS sensor. Resolution is up to 1920×1080 with frame rate up to 60 fps.
3.Fast, accurate and stable auto focusing technology.
4.Support AAC, MP3 and G.711A audio compression, 8000, 16000,32000,44100,48000 sampling frequency.
5. It adopts advanced ISP processing technology and algorithm, with good color reproduction and beautifying effect.
6. Support PTZ auto-flip function and easy installation.
7. Support VISCA, PELCO-D, PELCO-P protocols; Support automatic identification protocols.
8.It is widely used in beauty, jewelry, entertainment, games and other live broadcast application scenarios.

Relate series,click for more info

Specification

Model	12X
Camera Parameter
Optical Zoom	12X f＝3.9-46.8mm
Sensor	1/2.8 inch high quality HD CMOS sensor
Effective Pixels	16: 9, 2.07 megapixel
Video Format	HDMI video format 1080P60/50/30/25, 1080I60/50, 720P60/50 USB3.0 interface video format: Main Stream: YUY2/MJPEG/NV12/H.264/H.265:1920×1080P30,1280×720P30, 1024×576P30, 960×540P30, 800×448P30, 720×480P30, 640×360P30, 640×480P30, 320×176P30, 1080x1920P30 MJPEG/H.264/H.265: 1920×1080P60, 1280×720P60, 1024×576P60, 960×540P60, 800×448P60, 720×480P60, 640×360P60, 640×480P60, 320×176P60, 1080x1920P60 Sub Stream: YUY2/NV12: 640×360P30,640×480P30,320×176P30 MJPEG/H.264/H.265: 1920×1080P30, 1280×720P30, 1024×576P30, 960×540P30, 800×448P30, 720×480P30, 640×360P30, 640×480P30, 320×176P30, 1080x1920P30
View Angle	72.5°(W) 6.3°(T)
AV	F1.8 – F2.4
Minimum Illumination	0.5Lux (F1.8, AGC ON)
DNR	2D & 3D DNR
White Balance	Auto / Manual/ One Push/ Specify color temperature (range: 2400k-7100k)
Focus/Aperture/ Electronic Shutter	Auto/Manual/One Push Focus
Exposure Mode	Auto/Manual/Shutter Priority, Aperture Priority, Brightness Priority
Iris	F1.8 ～ F11, CLOSE
Shutter Speed	1/25~1/10000
BLC	ON/OFF
WDR	OFF/ Dynamic level adjustment
Video Adjustment	Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve
SNR	≥50dB
Input/output Interface
Video Interfaces	HDMI, LAN(POE), USB3.0(type B compatible with USB2.0) , RS232-IN, RS232-OUT, RS422 (compatible with RS485), A-IN, Rotary DIP switch, DC 12V Port, Power Switch
Video Stream	Dual stream output
Video Compression Format	LAN Interface: H.265, H.264, Dual stream output USB3.0 Interface: Main Stream:YUY2, MJPEG, H.264, NV12, H.265 Sub Stream:YUY2, MJPEG, H.264, NV12, H.265
Audio Input Interface	Double track 3.5mm linear input
Audio Output Interface	HDMI, SDI, LAN, USB3.0
Audio Compression Format	AAC/MP3/G.711A
Network Interface	10M/100M/1000M adaptive Ethernet port, support POE and audio/video output
Network Protocol	RTSP, RTMP, ONVIF, GB/T28181;Network VISCA control protocol;support remote upgrade, reboot and reset
Control Interface	RS232-IN, RS232-OUT, RS422 (compatible with RS485)
Control Protocol	VISCA/Pelco-D/Pelco-P, Baud Rate: 115200/38400/9600/4800/2400bps
USB Communication	UVC (Video)，UAC (Audio)
Power Interface	HEC3800 outlet (DC12V)
Power Adapter	Input: AC110V-AC220V ; Output: DC12V/2.5A
Input Voltage	DC12V±10%
Input Electric Current	Maximum: 1A
Power Consumption	Maximum: 12W

PTZ Parameter
Pan/Tilt Rotation	±170°, -30°～+90°
Pan Control Speed	0.1 – 100°/sec
Tilt Control Speed	0.1- 45°/sec
Preset Speed	Pan: 100°/sec, Tilt: 45°/sec
Preset Number	255 presets (10 presets via remote control)
Other Parameter
Stored Temperature	-10℃~+60℃
Storage Humidity	20%~95%
Working Temperature	-10℃~+50℃
Working Humidity	20%~80%
Dimension	181mmX115mmX149mm
Weight	1.15KG
Attachment
Package	Power Supply, RS232 Control Cable, USB3.0 Cable, Remote Controller, User Manual
Optional Accessories	Ceiling / Wall Mount (Extra Cost)
